National Health and Nutrition Examination Survey 2011-2012 data indicated that, in the United States, nearly one-fourth of children and over one-half of adolescents experienced dental caries in their permanent teeth. The purpose of this review was to summarize the available clinical evidence regarding the effect of dental sealants for the prevention and management of pit-and-fissure occlusal carious lesions in primary and permanent molars, compared with a control without sealants, with fluoride varnishes, or with other head-to head comparisons.The authors included parallel and split-mouth randomized controlled trials that included at least 2 years of follow-up, which they identified using MEDLINE (via PubMed), Embase, LILACS, the Cochrane Central Register of Controlled Trials, and registers of ongoing trials. Pairs of reviewers independently conducted the selection of studies, data extraction, risk of bias assessments, and quality of the evidence assessments by using the Grading of Recommendations Assessment, Development and Evaluation approach.Of 2,869 records screened, the authors determined that 24 articles (representing 23 studies) proved eligible. Moderate-quality evidence suggested that participants who received sealants had a reduced risk of developing carious lesions in occlusal surfaces of permanent molars compared with those who did not receive sealants (odds ratio [OR], 0.15; 95% confidence interval [CI], 0.08-0.27) after 7 or more years of follow-up. When the authors compared studies whose investigators had compared sealants with fluoride varnishes, they found that sealants reduced the incidence of carious lesions after 7 or more years of follow-up (OR, 0.19; 95% CI, 0.07-0.51); however, this finding was supported by low-quality evidence. On the basis of the evidence, the authors could not provide a hierarchy of effectiveness among the studies whose investigators had conducted head-to-head comparisons. The investigators of 2 trials provided information about adverse events, but they did not report any adverse events.Available evidence suggests that sealants are effective and safe to prevent or arrest the progression of noncavitated carious lesions compared with a control without sealants or fluoride varnishes. Further research is needed to provide information about the relative merits of the different types of sealant materials.Copyright © 2016 American Academy of Pediatric Dentistry and American Dental Association. Published by Elsevier Inc. All rights reserved.

The aim of this study was to evaluate the effects of enamel or dentin bonding agent (DBA) and sealant viscosity on sealant microleakage.Sixty extracted human premolars were randomly divided into two equal groups (based on sealant viscosity) and each group was divided into three subgroups of 10 teeth. Group 1 (low viscosity sealant, Seal-Rite, Pulpdent, USA with 7.7% filler): Prophylaxis, enameloplasty, etching of occlusal surfaces with 38% of phosphoric acid gel, rinsing and drying, followed by (1) enamel bonding agent (EBA) (Margin Bond, Coltène/Whaledent AG) or (2) DBA (Excite, Ivoclar Vivadent AG, Liechtenstein) or (3) no bonding (NB) prior to sealant application. In Group 2, similar procedures were performed except for applying a high viscosity sealant (Seal-Rite, Pulpdent, The USA with 34.4% filler). Specimens were thermocycled and then immersed in a 0.5% basic fuchsine solution for 24 h next, buccolingual slices of samples were scored under a stereomicroscope. The Kruskal-Wallis and Mann-Whitney U-tests were used for data analysis.There was no significant difference between DBA, EBA, and NB subgroups in the microleakage scores in both groups. Low viscosity sealant had a lower microleakage than the high viscosity sealant in both DBA (P = 0.002) and NB (P = 0.041) subgroups.The results indicated that the use of low viscosity sealant reduced the microleakage of pit and fissure sealants. However, the use of a bonding agent before sealant placement didn't affect the microleakage.

Despite the growing tendency toward tooth-colored restorations in dentistry, polymerization shrinkage and subsequent marginal microleakage remains a problem. The aim of this in vitro study was to compare microleakage between silorane-based and methacrylate-based composite resins at different time intervals and with different restorative techniques.In this in vitro study, 108 sound extracted human molar teeth were used. Mesial and distal proximal class II boxes with dimensions of 1.5 mm depth and 4 mm width were prepared. The gingival margins of all cavities were 1 mm below the cement enamel junction. The teeth were randomly divided into three groups based on test materials. In the first group, the teeth were restored by a nanocomposite (Filtek Z350XT, 3MESPE) and SE Bond adhesive (Kuraray, Japan), in the second group, the teeth were restored with a silorane-based (Filtek P90, 3MESPE) and Filtek P90 Adhesive (3M ESPE, USA) and in the third group, the teeth were restored with a microhybrid posterior composite resin (Filtek P60, 3MESPE) and SE Bond adhesive (Kuraray, Japan). Half of the proximal cavities in each of these three groups were restored in two horizontal layers and the other half in four horizontal layers. After a period of aging (24-h, 3-month and 6-month) in water and then application of 500 thermal cycles, the teeth were immersed for 24-h in 0.5% fuchsin and evaluated under a stereomicroscope at ×36 magnification to evaluate leakage in gingival margin. Data was statistically analyzed using Kruskal-Wallis and Mann-Whitney U-tests. P ≤ 0.05 was considered as significant.In Z350XT statistically significant differences were observed in microleakage in comparison of 24-h and 6-month intervals (P = 0.01) that was higher in 6-month. Comparison of microleakage in P90 and P60 composite resins was also statistically significant and was less in P90. Microleakage was not significantly different between P90 and Z350XT at 24-h. However, this difference was significant at 3-month and 6-month intervals. Differences in microleakage of P60 and Z-350XT composite resins were not statistically significant in all intervals (P = 0.38). P90 showed the lowest microleakage during storage in water. Z350XT had microleakage similar to P90 within 24-h, but after 6-month of storage in water, it showed the highest microleakage among all the groups. The number of layers (2 layers vs. 4 layers) did not result in any differences in microleakage scores of the composite resins (P = 0.42).Water storage times did not result in any significant effect on microleakage of P90 and P60.

To study the influence of resin based and lithium disilicate materials on the stress and strain distributions in adhesive class II mesio-occlusal-distal (MOD) restorations using numerical finite element analysis (FEA). To investigate the materials combinations in the restored teeth during mastication and their ability to relieve stresses.One 3D model of a sound lower molar and three 3D class II MOD cavity models with 95° cavity-margin-angle shapes were modelled. Different material combinations were simulated: model A, with a 10μm thick resin bonding layer and a resin composite bulk filling material; model B, with a 70μm resin cement with an indirect CAD-CAM resin composite inlay; model C, with a 70μm thick resin cement with an indirect lithium disilicate machinable inlay. To simulate polymerization shrinkage effects in the adhesive layers and bulk fill composite, the thermal expansion approach was used. Shell elements were employed for representing the adhesive layers. 3D solid CTETRA elements with four grid points were employed for modelling the food bolus and tooth. Slide-type contact elements were used between the tooth surface and food. A vertical occlusal load of 600 N was applied, and nodal displacements on the bottom cutting surfaces were constrained in all directions. All the materials were assumed to be isotropic and elastic and a static linear analysis was performed.Displacements were different in models A, B and C. Polymerization shrinkage hardly affected model A and mastication only partially affected mechanical behavior. Shrinkage stress peaks were mainly located marginally along the enamel-restoration interface at occlusal and mesio-distal sites. However, at the internal dentinal walls, stress distributions were critical with the highest maximum stresses concentrated in the proximal boxes. In models B and C, shrinkage stress was only produced by the 70μm thick resin layer, but the magnitudes depended on the Young's modulus (E) of the inlay materials. Model B mastication behavior (with E=20GPa) was similar to the sound tooth stress relief pattern. Model B internally showed differences from the sound tooth model but reduced maximum stresses than model A and partially than model C. Model C (with E=70GPa) behaved similarly to model B with well redistributed stresses at the occlusal margins and the lateral sides with higher stress concentrations in the proximal boxes. Models B and C showed a more favorable performance than model A with elastic biomechanics similar to the sound tooth model.Bulk filling resin composite with 1% linear polymerization shrinkage negatively affected the mechanical behavior of class II MOD restored teeth. Class II MOD direct resin composite showed greater potential for damage because of higher internal and marginal stress evolution during resin polymerization shrinkage. With a large class II MOD cavity an indirect composite or a lithium disilicate inlay restoration may provide a mechanical response close to that of a sound tooth.Copyright © 2017 The Academy of Dental Materials. Published by Elsevier Ltd. All rights reserved.

The purpose of this study was to investigate the consequences of using flowable composite as a liner beneath class I resin composite restorations on polymerization shrinkage stress and occlusal force. Models of class I resin composite restorations were generated. A control model received no flowable composite liner. Thirteen test models received different flowable composite liners with varying elastic modulus. Finite element analysis was used. The polymerization shrinkage of the resin composite and an occlusal force were simulated in the models. The stress and strain energy density in each model were investigated. The results demonstrated that all flowable composite linings were able to reduce polymerization shrinkage stress and occlusal force in enamel, dentin, the hybrid layer, and the adhesive layer to various degrees in tooth-restoration systems. Therefore, additional techniques may be applied to reduce the remaining stress and to ensure the long-term success of restorations.

To investigate the influence of different resin composite and glass ionomer cement material combinations in a "bi-layer" versus a "single-layer" adhesive technique for class I cavity restorations in molars using numerical finite element analysis (FEA).Three virtual restored lower molar models with class I cavities 4mm deep were created from a sound molar CAD model. A combination of an adhesive and flowable composite with bulk fill composite (model A), of a glass ionomer cement with bulk fill composite (model B) and of an adhesive with bulk fill composite (model C), were considered. Starting from CAD models, 3D-finite element (FE) models were created and analyzed. Solid food was modeled on the occlusal surface and slide-type contact elements were used between tooth surface and food. Polymerization shrinkage was simulated for the composite materials. Physiological masticatory loads were applied to these systems combined with shrinkage. Static linear analyses were carried out. The maximum normal stress criterion was adopted as a measure of potential damage.All models exhibited high stresses principally located along the tooth tissues-restoration interfaces. All models showed a similar stress trend along enamel-restoration interface, where stresses up to 22MPa and 19MPa was recorded in the enamel and restoration, respectively. A and C models showed a similar stress trend along the dentin-restoration interface with a lower stress level in model A, where stresses up to 11.5MPa and 7.5MPa were recorded in the dentin and restoration, respectively, whereas stresses of 17MPa and 9MPa were detected for model C. In contrast to A and C models, the model B showed a reduced stress level in dentin, in the lower restoration layer and no stress on the cavity floor.FE analysis supported the positive effect of a "bi-layer" restorative technique in a 4mm deep class I cavities in lower molars versus "single-layer" bulk fill composite technique.Copyright © 2019 The Academy of Dental Materials. Published by Elsevier Inc. All rights reserved.

To study the influence of the resin bonding layer thickness and the bulk filling material stiffness in adhesive class II mesio-occlusal-distal (MOD) restorations using numerical finite element analysis (FEA).Four 3D-FE models of teeth restored with different filling material stiffness and resin bonding layer thickness were built-up and analyzed. The 3D model of a sound lower molar was also analyzed and compared with restored ones. The tooth tissues (enamel, dentin), dental restoration and bolus on the occlusal surface, was divided into 3D solid CTETRA elements with four grid points. The adhesive bonding around the dental restoration was modeled with shell elements. Polymerization shrinkage was simulated with a thermal expansion approach. Mechanical behavior of restored models in terms of stress and displacement distributions, under the combination effects of polymerization shrinkage and occlusal load (600 N), was analyzed. All the materials were assumed to behave as elastic materials throughout the entire deformation.Numerical results show that the mechanical response of the restored models was very different compared to the sound tooth ones, where the stress was uniformly distributed from enamel to dentin with no critical stress concentration. In the restored models, the highest stress values were detected in the enamel, near the enamel-dentin interface and in the bulk restorative material. Tooth preparations A and B showed lower gradient stresses than corresponding C and D. The value of the vertical displacement components in models A and B were higher than corresponding C and D. The maximum displacement values were mainly located around the groove and were higher by an order of magnitude than the sound models. The results showed better mechanical response with models A and B compared to C and D. It is also evident that resin bonding thickness slightly affected the stress level of the restored teeth.Class II MOD direct bulk resin composite restorations showed a high susceptibility to damage at the marginal and internal tissue interfaces depending on their own stiffness. The use of resin-based bulk filling materials is not recommended for large class II MOD adhesive restorations due to mechanical behavior failure risk.

To investigate the influence of specific resin-composite, glass ceramic and glass ionomer cement (GIC) material combinations in a "multi-layer" technique to replace enamel and dentin in class II mesio-occlusal-distal (MOD) dental restorations using 3D-Finite Element Analysis (FEA).Four 3D-FE models (A-D) of teeth, adhesively restored with different filling materials, were created and analyzed in comparison with a 3D model (E) of a sound lower molar. Models A, B & C had "multilayer" constructions, consisting of three layers: adhesive, dentin replacement and enamel replacement. Model A: had a low modulus (8GPa) composite replacing dentin and a higher modulus (12GPa) composite replacing enamel. Model B: had a GI cement replacing dentin and a higher modulus (12GPa) composite replacing enamel. Model C: had a low modulus (8GPa) composite replacing dentin and a very high modulus (70GPa) inlay replacing enamel. Model D: had a lithium disilicate inlay replacing both dentin and enamel with a luting cement base-layer. Polymerization shrinkage effects were simulated and a load of 600N was applied. All the materials were assumed to behave elastically throughout the entire deformation.Model A showed the highest stress distribution along all the adhesive interfaces of the shrinking resin-based materials with a critical condition and failure risk marginally and internally. Model D, by contrast, showed a more favorable performance than either of the multilayer groups (A-C). Stress and displacement plots showed an elastic response similar to that obtained for the sound tooth model. Model B and Model C performed according to their bilayer material properties. The use of a non-shrink dentin component simulating a GIC clearly affected the shrinkage stress at the basis of the Model B; while the bulk resin composite having a 12GPa Young's modulus and linear polymerization shrinkage of 1% strongly influenced the biomechanical response in the bucco-lingual direction.Direct resin-based composite materials applied in multilayer techniques to large class II cavities, with or without shrinking dentin layers, produced adverse FEA stress distributions and displacements. An indirect lithium disilicate inlay used to replace lost dentin and enamel in posterior restored teeth generated lower stress levels, within the limits of the elastic FEA model.Crown Copyright © 2017. Published by Elsevier Ltd. All rights reserved.

The present study analysed the effects of different occlusal loading on premolars displaying various non-carious cervical lesions morphologies, restored (or not) with composites, by 3D finite element analysis.A three-dimensional digital model of a maxillary premolar was generated using CAD software. Three non-carious cervical lesions morphological types were simulated: wedged-shaped, saucer and mixed. All virtual models underwent three loading types (100 N): vertical, buccal and palatal loading. The simulated non-carious cervical lesions morphologies were analysed with and without restorations to consider specific regions, such as the occlusal and gingival walls as well as the depth of the lesions. Data summarizing the stress distribution were obtained in MPa using Maximum Principal Stress.Palatal loads were responsible for providing the highest values of accumulated tensile stress on the buccal wall; 27.66 MPa and 25.76 MPa for mixed and wedged-shaped morphologies, respectively. The highest tensile values found on non-carious cervical lesions morphologies restored with composite resin were 5.9 MPa in the mixed morphology, similar to those found on sound models despite their morphologies and occlusal loading.The various non-carious cervical lesions morphologies had little effect on stress distribution patterns, whereas the loading type and presence of composite restorations influenced the biomechanical behaviour of the maxillary premolars.© 2015 Australian Dental Association.

The C-Factor has been used widely to rationalize the changes in shrinkage stress occurring at the tooth/resin-composite interfaces. Experimentally, such stresses have been measured in a uniaxial direction between opposed parallel walls. The situation of adjoining cavity walls has been neglected. The aim was to investigate the hypothesis that: within stylized model rectangular cavities of constant volume and wall thickness, the interfacial shrinkage-stress at the adjoining cavity walls increases steadily as the C-Factor increases.Eight 3D-FEM restored Class I 'rectangular cavity' models were created by MSC.PATRAN/MSC.Marc, r2-2005 and subjected to 1% of shrinkage, while maintaining constant both the volume (20 mm(3)) and the wall thickness (2 mm), but varying the C-Factor (1.9-13.5). An adhesive contact between the composite and the teeth was incorporated. Polymerization shrinkage was simulated by analogy with thermal contraction. Principal stresses and strains were calculated. Peak values of maximum principal (MP) and maximum shear (MS) stresses from the different walls were displayed graphically as a function of C-Factor. The stress-peak association with C-Factor was evaluated by the Pearson correlation between the stress peak and the C-Factor.The hypothesis was rejected: there was no clear increase of stress-peaks with C-Factor. The stress-peaks particularly expressed as MP and MS varied only slightly with increasing C-Factor. Lower stress-peaks were present at the pulpal floor in comparison to the stress at the axial walls. In general, MP and MS were similar when the axial wall dimensions were similar. The Pearson coefficient only expressed associations for the maximum principal stress at the ZX wall and the Z axis.Increase of the C-Factor did not lead to increase of the calculated stress-peaks in model rectangular Class I cavity walls.Copyright © 2011 Academy of Dental Materials. Published by Elsevier Ltd. All rights reserved.

Thermo-mechanical finite element analyses in 3-D models are described for determination of the stress levels due to thermal and mechanical loads in a healthy and restored tooth. Transient thermo-mechanical analysis simulating the ingestion of cold and hot drinks was performed to determine the temperature distribution in the models of the teeth, followed by linear elastic stress analyses. The thermal loads were applied on the occlusal and lingual surfaces. Subsequently, coupled variation of the temperature and mastication loading was considered. The vertical loading was distributed at occlusal points, adding up to 180 N. Maximum stresses were verified in resin restoration under thermal loads. When studying coupled effect of mechanical loading with that arising from thermal effects, higher tensile stress values occurred in porcelain restorations, especially at the restoration-dentin interface. Regions of high tensile stress were detected and their possible clinical significance with respect to restoration damage and microleakage were discussed.
